| Item | Value |
|---|---|
| Measured gases | CH4methane、LEL flammable gas |
| Measuring range | 0-100 %LEL |
| Detection principle | catalytic combustion |
| Accuracy | ±2%F.S. |
| Resolution | |
| Response time | <15s |
| Ingress protection | IP65 |
| Explosion protection | |
| Operating temperature | -40℃ ~+70℃ |
| Power supply | 9~28VDC |
| Output signal |
RAEAlert LEL is a Flammable gas detectors with modular design, intelligent sensor detection technology, integral flameproof (d) structure, and fixed installation. Its intelligent processing platform and Smart sensor technology realize sensor interchangeability, offline calibration and zero point self-calibration functions. The standard configuration is with dot matrix LCD liquid crystal display, three-wire 4~20mA analog and RS485 digital signal output, and optional configuration as programmable switching output and other modules, according to user needs to provide customized products, but also support output signal fine-tuning and other functions, convenient for system networking and maintenance.
.png)
RAEAlert LEL flammable gas detector probe FGM-3100 gas detector reference diagram
FGM-3100Flammable gas detectors probe product data is detailed
.png)
%E4%B8%AD%E6%96%87%E6%8A%80%E6%9C%AF%E5%8F%82%E6%95%B0_%E9%A1%B5%E9%9D%A2_2.jpg)
Part Number《2026》: China approved. FGM-3100/3100S(: H-D04-BC30-104), ; Price excluded, .
| Category | Part Number | Description |
|---|---|---|
| Instruments/Modules | H-D04-BC30-104 | methane calibration 0-100 % LEL China CCCF |
| Instruments/Modules | H-D04-BC30-105 | methane calibration 0-100 % LEL with display and remote controller China CCCF |
| Instruments/Modules | H-D04-BC30-108 | methane calibration 0-100 % LEL SP-07Plus(red indicator) China CCCF |
| Instruments/Modules | H-D04-BC30-109 | methane calibration 0-100 % LEL with display and remote controller、SP-07Plus(red indicator) China CCCF |
| Instruments/Modules | H-D04-BC31-104 | methane calibration 0-100 % LEL with display and relay China CCCF |
| Instruments/Modules | H-D04-BC31-105 | methane calibration 0-100 % LEL with display and relay、remote controller China CCCF |
| Instruments/Modules | H-D04-BC31-108 | methane calibration 0-100 % LEL with display and relay、SP-07Plus(red indicator) China CCCF |
| Instruments/Modules | H-D04-BC31-109 | methane calibration 0-100 % LEL with display and relay、remote controller、SP-07Plus(red indicator) China CCCF |
| Instruments/Modules | H-D04-BS30-104 | methane calibration 0-100 % LEL,stainless steel China CCCF |
| Instruments/Modules | H-D04-BS30-105 | methane calibration 0-100 % LEL with display and remote controller,stainless steel China CCCF |
| Instruments/Modules | H-D04-BS30-108 | methane calibration 0-100 % LEL SP-07Plus(red indicator),stainless steel China CCCF |
| Instruments/Modules | H-D04-BS30-109 | methane calibration 0-100 % LEL with display and remote controller、SP-07Plus(red indicator),stainless steel China CCCF |
| Instruments/Modules | H-D04-BS31-104 | methane calibration 0-100 % LEL with display and relay,stainless steel China CCCF |
| Instruments/Modules | H-D04-BS31-105 | methane calibration 0-100 % LEL with display and relay、remote controller,stainless steel China CCCF |
| Instruments/Modules | H-D04-BS31-108 | methane calibration 0-100 % LEL with display and relay、SP-07Plus(red indicator),stainless steel China CCCF |
| Instruments/Modules | H-D04-BS31-109 | methane calibration 0-100 % LEL with display and relay、remote controller、SP-07Plus(red indicator),stainless steel China CCCF |
