| Item | Value |
|---|---|
| Measured gases | LNG LNG, CH4methane, O2oxygen, H2Shydrogen sulfide, LEL flammable gas |
| Measuring range | 0-100% LEL (low explosion limit) 0-5% (volume ratio) |
| Detection principle | catalytic combustion、electrochemical |
| Accuracy | |
| Resolution | |
| Response time | |
| Ingress protection | |
| Explosion protection | |
| Operating temperature | |
| Power supply | |
| Output signal |
Small size and light weight (6*10*3.3cm/211g)
In the field of gas detection, MC is indeed a cost-effective detector
The shockproof housing is rugged and suitable for use in harsh environments
The LCD displays the gas concentration continuously in real time
Two x 5 dry NiMH rechargeable batteries (16-18 hours of operation)
Features a 95 dB audible alarm and two bright wide-angle visual alarms
The instrument has a built-in vibration alarm, making it suitable for use in high-noise environments
Background light: The background light turns on automatically when the light is dim/alarm/when the user presses the button
Four-level alarm: low and high limit alarms are suitable for all gases, TWA (time-weighted average) and STEL (short-time exposure value) alarms are suitable for H2S and CO, and OL (over-measuring range alarm) is suitable for flammable gases
Simple automatic calibration calibration procedures and plug-in replaceable electrochemical sensors
Record TWA, STEL and peak gas composition and concentration display when required
Full-function self-test: sensor, battery and circuit integrity, three alarms of sound and light vibration
Random equipment: sensor, two alkaline No. 5 batteries, alligator clip, calibration hose, calibration cover and Chinese manual
There is no Product highlights.
Measuring range: 0-100% LEL (low explosion limit) 0-5% (volume ratio)
Calibration: Automatic calibration and zeroing
Backlight: Automatically turn on the backlight when low-light/alarm/user needs
Sensor: Plug-in replaceable electrochemical sensor (temperature compensation)
Alarm indication: Clearly indicates alarm levels in both audible and visual ways
Visual alarm: flashing wide-angle alarm lens and two red LED warning lights and LCD readings and alarm levels
Audible alarm: Acoustic pulse up to 95 dB at 0.3 meters from the detector
Vibration alarm: pulse vibration in alarm state and other alarm situations
Other alarms: low battery, over Measuring range, shutdown warning, sensor failure
Display: LCD digital display readings and status instructions
Reading: Displays the composition/concentration of the gas after the self-test is turned on
TWA/STEL: Records STEL and TWA exposure values display
Peak: Gas exposure peaks can be recorded and displayed as required
Alarm settings: Displayed when automatically activated or when the detector is started
Testing: (Automatic) full-featured self-test at startup
General specifications: Robust composite material with complete impact protection
Operating temperature: -20 to 50 degrees
Relative humidity: 5% to 95% RH (non-condensing)
Ingress protection: IP65 in accordance with EMC Directive 89/336/EMC
Operating time: 16-18 hours Two alkaline No. 5 batteries
14-16 hours two NiMH rechargeable batteries
Volumetric weight: 6×10×3.3 cm / 211 g
Sensor service life: greater than or equal to 3 years
It is suitable for industrial safety monitoring and on-site inspection scenarios.
This module lists part numbers and descriptions for model selection. Price information is excluded.
| Category | Part Number | |
|---|---|---|
| Main Unit | MCXL-XWHM-Y-CN | GasAlert MicroClip XL %LEL(F) O2 H2S CO (Yellow) |
| Main Unit | MCXL-XWHM-B-CN | GasAlert MicroClip XL %LEL(F) O2 H2S CO (Black) |
| Main Unit | MCXL-XWH0-Y-CN | GasAlert MicroClip XL %LEL(F) O2 H2S (Yellow) |
| Main Unit | MCXL-XWH0-B-CN | GasAlert MicroClip XL %LEL(F) O2 H2S (Black) |
| Main Unit | MCXL-XW0M-Y-CN | GasAlert MicroClip XL %LEL(F) O2 CO (Yellow) |
| Main Unit | MCXL-XW0M-B-CN | GasAlert MicroClip XL %LEL(F) O2 CO (Black) |
| Main Unit | MCXL-X0HM-Y-CN | GasAlert MicroClip XL O2 H2S CO (Yellow) |
| Main Unit | MCXL-X0HM-B-CN | GasAlert MicroClip XL O2 H2S CO (Black) |
| Main Unit | MCXL-XW00-Y-CN | GasAlert MicroClip XL %LEL(F) O2 (Yellow) |
| Main Unit | MCXL-XW00-B-CN | GasAlert MicroClip XL %LEL(F) O2 (Black) |
| Main Unit | MCXL-00HM-Y-CN | GasAlert MicroClip XL H2S CO (Yellow) |
| Main Unit | MCXL-00HM-B-CN | GasAlert MicroClip XL H2S CO (Black) |
| Main Unit | MCXL-X0H0-Y-CN | GasAlert MicroClip XL O2 H2S (Yellow) |
| Main Unit | MCXL-X0H0-B-CN | GasAlert MicroClip XL O2 H2S (Black) |
| Main Unit | MCXL-X00M-Y-CN | GasAlert MicroClip XL O2 CO (Yellow) |
| Main Unit | MCXL-X00M-B-CN | GasAlert MicroClip XL O2 CO (Black) |
| Main Unit | MCXL-X000-Y-CN | GasAlert MicroClip XL O2 (Yellow) |
| Main Unit | MCXL-X000-B-CN | GasAlert MicroClip XL O2 (Black) |
| Main Unit | MCXL-00H0-Y-CN | GasAlert MicroClip XL H2S (Yellow) |
| Main Unit | MCXL-00H0-B-CN | GasAlert MicroClip XL H2S (Black) |
| Main Unit | MCXL-000M-Y-CN | GasAlert MicroClip XL CO (Yellow) |
| Main Unit | MCXL-000M-B-CN | GasAlert MicroClip XL CO (Black) |
| 3CF Version | MCXL-XWHM-Y-3C | MicroClip XL %LEL(F) O2 H2S CO(Yellow, 3CF) |
| 3CF Version | MCXL-XWHM-B-3C | MicroClip XL %LEL(F) O2 H2S CO(Black, 3CF) |
| 3CF Version | MCXL-XWH0-Y-3C | MicroClip XL %LEL(F) O2 H2S(Yellow, 3CF) |
| 3CF Version | MCXL-XWH0-B-3C | MicroClip XL %LEL(F) O2 H2S(Black, 3CF) |
| 3CF Version | MCXL-XW0M-Y-3C | MicroClip XL %LEL(F) O2 CO(Yellow, 3CF) |
| 3CF Version | MCXL-XW0M-B-3C | MicroClip XL %LEL(F) O2 CO(Black, 3CF) |
| 3CF Version | MCXL-XW00-Y-3C | MicroClip XL %LEL(F) O2(Yellow, 3CF) |
| 3CF Version | MCXL-XW00-B-3C | MicroClip XL %LEL(F) O2(Black, 3CF) |
| Replacement Parts | MCXL-FC1 | Front housing assembly (Yellow) |
| Replacement Parts | MCXL-FC1B | Front housing assembly (Black) |
| Replacement Parts | MCXL-BC1 | Rear housing assembly(Yellow, includes clip and screws) |
| Replacement Parts | MCXL-BC1B | Rear housing assembly(Black, includes clip and screws) |
| Replacement Parts | MCXL-FPCB1 | Flexible PCB assembly |
| Replacement Parts | MCXL-MPCB1 | Main PCB assembly(includes battery and screws) |
| Replacement Parts | MCXL-FC1-3C | Front housing assembly(Yellow, 3CF) |
| Replacement Parts | MCXL-FC1B-3C | Front housing assembly(Black, 3CF) |
| Replacement Parts | MCXL-MPCB1-3C | Main PCB assembly(includes battery and screws, 3CF) |
| General Accessories | GA-NS-1 | Neck strap with safety release(Neck strap with safety release) |
| General Accessories | GA-PA-1-AU | Regional power adapter(AU version) |
| General Accessories | MC-AS01 | Manual aspirator pumpKit(includes, 0.3m/1ft) |
| General Accessories | MC-TC-1 | Test cap and hose(1ft/0.3m)replacement part |
| General Accessories | MC-AF-K1 | Auxiliary filterKit(includes 5 pcsfilter element) |
| General Accessories | MC-AF-1 | Auxiliary filter adapter(without filter element) |
| General Accessories | MC-SS-AF-K1 | Auxiliary filter filter element(10 pcs/pack) |
| General Accessories | MC-CK-DL | confined spaceKit(Deluxe) |
| General Accessories | MC-CK-CC | Carrying case(with foam and insert) |
| General Accessories | GA-VPA-1 | 12-24V vehicle power adapter(plug type) |
| General Accessories | GA-PA-3 | 12-24V hardwired vehicle power adapter |
| General Accessories | GA-PA-1-EU | Regional power adapter(EU version) |
| General Accessories | GA-PA-1-MC5-EU | 5-unit chargerRegional power adapter(EU version) |
| Replacement Parts | MC-LCD-K1 | LCD screen replacementKit |
| Replacement Parts | MC-LCD-K1-3C | LCD screen replacementKit(3CF version) |
| Replacement Parts | MC-SCREW-K1 | screw replacementKit(20 pcs/pack) |
| Replacement Parts | MC-DUM | combustible-position dummySensor(Dummy) |
| Replacement Parts | GA-VM-2 | Vibration motor replacement |
